Tubular Lifting Sockets

Tubular Lifting Sockets

Manufactured from either high grade precision steel tube in zinc plated finish or stainless steel tube. The sockets are supplied with an (Rd) round thread as standard. Euro Accessories Tubular Lifting Sockets are designed to offer high load bearing capabilities in both axial and shear loading instances. When using tubular lifting sockets, additional reinforcement through the cross hole must always be utilised.

Product Code Thread Dia. (Rd) Length (mm) SWL (kg) Pack Size Pallet Size
SLT1240 12 40 500 700 14000
SLT1654 16 54 1200 250 6000
SLT2067 20 67 2000 100 4200
SLT2478 24 78 2500 100 2400
SLT30105 30 105 4000 50 1200
SLT36125 36 125 6300 25 725
SLT42145 42 145 8000 20 600
SLT52195 52 195 12500 10 200

Also available in stainless steel. (Add SS to Product Code)

  • Data Sheet

    Guidance on Choice of Socket (Download)

    Tubular Lifting Socket Data Sheet (Download)

  • Technical Manual

    Threaded Socket Technical Manual (Download)

  • Certificates

    UKCA Declaration of Conformace (Download)

    EU CE Declaration of Conformance (Download)

    UK Test Certificate Example (Download)
