Spread Anchors

Spread Anchors

The Spread Anchor is suitable for lifting both narrow wall type units and slab units. In certain applications it can be utilised without the need for further reinforcement.

Product Code Length (mm) SWL (kg) Pack Size Pallet Size
LAS007110 110 700 150 6000
LAS014110 110 1400 150 6000
LAS014160 160 1400 75 3000
LAS025120 120 2500 50 2000
LAS025150 150 2500 50 2000
LAS025200 200 2500 40 1500
LAS025250 250 2500 30 1200
LAS050180 180 5000 30 800
LAS050240 240 5000 20 500
LAS050400 400 5000 10 400
LAS075260 260 7500 8 400
LAS075300 300 7500 8 300
LAS075420 420 7500 8 250
LAS100300 300 10000 6 200
LAS100370 370 10000 6 200
LAS100520 520 10000 6 150
LAS140370 370 14000 Each 200
LAS140460 460 14000 Each 150
LAS220500 500 22000 Each 100
LAS220620 620 22000 Each 80

Also available in galvanised. (Add G to Product Code)

  • Data Sheet

    Guidance on Choice of Anchor (Download)

    Spread Anchor Data Sheet (Download)

  • Technical Manual

    Spread Anchor System Technical Manual (Download)

  • Certificates

    UKCA Declaration of Conformance (Download)

    EU CE Declaration of Conformance (Download)

    UK Test Certificate Example (Download)
