Rod Slot Anchors

Rod Slot Anchors

The Rod Anchor is manufactured from standard reinforcement steel yet maintains the head dimensions of the standard Pin Anchors and utilises the same formers and lifting clutches. Lifting loads are transferred into the surrounding concrete along the entire embedded length of the Rod Anchor. This makes the anchor ideal for use in very thin panels where concentrated loads can potentially damage the surrounding concrete.

Product Code (Self Colour) Product Code (Galvanised) SWL (kg) Length (mm) Pack Size Pallet Size
LAPTS025400 LAPTS025400G 2500 400 50 1000
LAPTS025520 LAPTS025520G 2500 520 30 1000
LAPTS050580 LAPTS050580G 5000 580 10 500
LAPTS050790 LAPTS050790G 5000 790 10 400
LAPTS050900 LAPTS050900G 5000 900 10 300
LAPTS075750 LAPTS075750G 7500 750 10 150
LAPTS0751150 LAPTS0751150G 7500 1150 10 100
LAPTS1000870 LAPTS1000870G 10000 870 5 100
LAPTS1001300 LAPTS1001300G 10000 1300 5 100
LAPTS1501080 LAPTS1501080G 15000 1080 5 50
LAPTS1501550 LAPTS1501550G 15000 1550 5 50
  • Data Sheet

    Rod Slot Anchors Data Sheet (Download)

  • Technical Manual

    Anchor Pin System Technical Manual (Download)

  • Certificates

    UKCA Declaration of Conformance (Download)

    EU CE Declaration of Conformance (Download)

    UK Test Certificate Example (Download)
