Anchor Pin Ring Clutch

Anchor Pin Ring Clutch

The Pin Anchor Ring Clutch is a robust lifting devise manufactured from several cast components. The lifting clutch is designed to fit only the Pin Anchors and Recess Formers for the chosen load category. This built in safety feature, ensures that mismatching of load groups cannot occur.

Product Code Load Group (kg) Length (mm)
LAPRC013 1000 - 1300 165
LAPRC025 2000 - 2500 205
LAPRC050 4000 - 5000 240
LAPRC100 7500 - 10000 346
LAPRC200 15000 - 20000 520
LAPRC320 32000 590
LAPRC450 45000 590
  • Data Sheet

    Anchor Pin Ring Clutch Data Sheet (Download)

  • Technical Manual

    Anchor Pin System Technical Manual (Download)

  • Certificates

    UKCA Declaration of Conformance (Download)

    EU CE Declaration of Conformance (Download)

    UK Test Certificate Example (Download)
