IP PIR Insulation Boards

IP PIR Insulation Boards

IP PIR 022 is a straight edge insulation panel with a core of rigid polyiscocyanurate (PIR) foam, faced on both sides with gasdiffusiontight multi-layered complex. Specially designed for use with precast concrete sadwich panels.

Product Code Thickness (mm) Width (mm) Length (mm) Thermal Conductivity (w/mk) RD - Value (m2/KW)
IPPIR030 30 1200 2400 0.022 1.35
IPPIR040 40 1200 2400 0.022 1.8
IPPIR050 50 1200 2400 0.022 2.25
IPPIR060 60 1200 2400 0.022 2.7
IPPIR070 70 1200 2400 0.022 3.15
IPPIR080 80 1200 2400 0.022 3.6
IPPIR090 90 1200 2400 0.022 4.05
IPPIR100 100 1200 2400 0.022 4.5
IPPIR110 110 1200 2400 0.022 5
IPPIR120 120 1200 2400 0.022 5.45
IPPIR130 130 1200 2400 0.022 5.9
IPPIR140 140 1200 2400 0.022 6.35
IPPIR150 150 1200 2400 0.022 6.8
IPPIR160 160 1200 2400 0.022 7.25
IPPIR170 170 1200 2400 0.022 7.7
  • Data Sheet

    IP PIR Insulation Data Sheet (Download)
