Econac Transport Anchors

ECA-Lift® Transport Anchors

The patented ECA-Lift®-anchor is the better anchor for twin walls. It consists of a compression element, made out of high resistance fiberglass, connected by a steel wire. There are two types of anchors 3 ton & 5 ton, both with a minimum safety factor of three.

All sizes are available with an additional support spacer for extra stability.

Slide title

Profile:
40/25, 49/30, 54/33 & 72/49

Button
Slide title

Write your caption here

Button

Product Code	Width (mm)	Rope Dia. (mm)	Length (mm)	SWL (kg)	Pallet Size
TAE3T120	120	9.5	616	3000	780
TAE3T130	130	9.5	613	3000	780
TAE3T140	140	9.5	610	3000	720
TAE3T150	150	9.5	607	3000	720
TAE3T160	160	9.5	604	3000	660
TAE3T170	170	9.5	602	3000	660
TAE3T180	180	9.5	649	3000	600
TAE3T190	190	9.5	646	3000	600
TAE3T200	200	9.5	643	3000	540
TAE3T210	210	9.5	640	3000	540
TAE3T220	220	9.5	637	3000	480
TAE3T230	230	9.5	634	3000	480
TAE3T240	240	9.5	682	3000	480
TAE3T250	250	9.5	679	3000	480
TAE3T260	260	9.5	676	3000	480
TAE3T270	270	9.5	673	3000	420
TAE3T280	280	9.5	670	3000	420
TAE3T290	290	9.5	667	3000	420
TAE3T300	300	9.5	665	3000	360
TAE3T310	310	9.5	712	3000	360
TAE3T320	320	9.5	709	3000	360
TAE3T330	330	9.5	706	3000	300
TAE3T340	340	9.5	703	3000	300
TAE3T350	350	9.5	700	3000	300
TAE3T360	360	9.5	697	3000	250
TAE3T370	370	9.5	745	3000	250
TAE3T380	380	9.5	742	3000	250
TAE3T390	390	9.5	739	3000	200
TAE3T400	400	9.5	736	3000	200

Product Code	Width (mm)	Rope Dia. (mm)	Length (mm)	SWL (kg)	Pallet Size
TAE5T120	120	14	666	5000	550
TAE5T130	130	14	663	5000	550
TAE5T140	140	14	660	5000	500
TAE5T150	150	14	707	5000	500
TAE5T160	160	14	704	5000	450
TAE5T170	170	14	702	5000	450
TAE5T180	180	14	699	5000	400
TAE5T190	190	14	696	5000	400
TAE5T200	200	14	693	5000	380
TAE5T210	210	14	690	5000	380
TAE5T220	220	14	737	5000	340
TAE5T230	230	14	734	5000	340
TAE5T240	240	14	732	5000	340
TAE5T250	250	14	729	5000	340
TAE5T260	260	14	726	5000	340
TAE5T270	270	14	723	5000	300
TAE5T280	280	14	770	5000	300
TAE5T290	290	14	767	5000	300
TAE5T300	300	14	765	5000	300
TAE5T310	310	14	762	5000	300
TAE5T320	320	14	759	5000	250
TAE5T330	330	14	756	5000	250
TAE5T340	340	14	753	5000	250
TAE5T350	350	14	800	5000	250
TAE5T360	360	14	797	5000	200
TAE5T370	370	14	795	5000	200
TAE5T380	380	14	792	5000	200
TAE5T390	390	14	789	5000	150
TAE5T400	400	14	786	5000	150
