Curved Pin Anchors

Curved Pin Anchors

Designed for lifting very shallow slab units, this anchor utilises 4 additional reinforcement bars placed in pairs over the integral plate to transfer loads into the surrounding concrete.  These anchors are forged from round mild steel. They are offered in either mild steel or hot dip galvanised finish. Each item is clearly marked with Euro Accessories branding, it’s maximum safe working load, CE marking and batch number.

Product Code (Self Colour) Product Code (Galvanised) SWL (kg) Length (mm) Pack Size Pallet Size
LAPC013227 LAPC013227G 1300 227 100 4000
LAPC025268 LAPC025268G 2500 268 50 2000
LAPC050446 LAPC050446G 5000 446 25 600
LAPC075664 LAPC075664G 7500 664 10 250
LAPC100667 LAPC100667G 10000 667 10 200
LAPC150825 LAPC150825G 15000 825 5 100
LAPC200986 LAPC200986G 20000 986 1 60
LAPC3201150 LAPC3201150G 32000 1150 1 30
  • Data Sheet

    Curved Pin Anchor Data Sheet (Download)

  • Technical Manual

    Anchor Pin System Technical Manual (Download)

  • Certificates

    UKCA Declaration of Conformance (Download)

    EU CE Declaration of Conformance (Download)

    UK Test Certificate Example (Download)
