Cast-in Loops

Cast-in Loops

Cast in Lifting Loops are one of the most economic lifting systems available to the precast concrete manufacturer. They are designed for lifting precast concrete units where the lifting points side will be hidden from view once it is installed in its final position. Lifting equipment, such as crane hooks can be attached directly onto these loops without the need for any other lifting devices.

Cast in Loops are manufactured from galvanised mild steel rope. They have a swaged connecting ferrule and a colour coded tag that clearly identifies the safe working load along with the manufactures logo.

Product Code Length (mm) Rope Dia. (mm) Tag Colour SWL (kg)
SCL00800 200 6 White 800
SCL01200 220 7 Red 1200
SCL01600 235 8 Purple 1600
SCL02000 255 9 Light Green 2000
SCL02500 280 10 Charcoal 2500
SCL04000 330 12 Dark Green 4000
SCL05200 385 14 Orange 5200
SCL06300 385 16 Blue 6300
SCL08000 430 18 Light Grey 8000
SCL10000 470 20 Pink 10000
SCL12500 510 22 Yellow 12500
SCL16000 560 26 Lilac 16000
SCL20000 610 28 Grey 20000
SCL25000 670 32 Brown 25000
SCL28000 680 36 Dark Orange 28000
SCL32000 770 36 Dark Orange 32000
SCL37000 950 40 Dark Orange 37000
SCL42000 1000 44 Dark Orange 42000
SCL47000 1100 44 Dark Orange 47000
SLC52000 1200 48 Dark Orange 52000
SCL57000 1350 48 Dark Orange 57000
  • Data Sheet

    Cast-in Loops Data Sheet (Download)

  • Technical Manual

    Threaded Socket System Technical Manual (Download)

  • Certificates

    Declaration of Conformance (Download)
