Angled Fixing Sockets

Angled Fixing Sockets

Angled Fixing Sockets are designed for quick and easy connection of precast units with generous placement tolerances. These sockets should only be used where on site fixing tolerances are sufficiently flexible. The socket is manufactured from either high grade precision steel tube with a zinc plated finish, or a stainless steel grade A2 tube (Grade 304). The socket is supplied with the flat end bent perpendicular to its axis. This provides a means of anchoring the socket into the concrete and negates the need for additional reinforcement.

Product Code Thread Dia. (M) Length (mm) Load (kN) Pack Size Pallet Size
SFA08050 8 50 1.80 500 48000
SFA10035 10 35 2.40 600 30000
SFA12045 12 45 4.00 300 12000
SFA12070 12 70 8.00 200 9400
SFA16060 16 60 9.50 150 7200
SFA16100 16 100 13.0 50 3000
SFA20070 20 70 12.0 100 3000
SFA20100 20 100 16.0 40 2400
SFA24080 24 80 16.0 40 2400

Also available in stainless steel. (Add SS to Product Code)

  • Data Sheet

    Guidance on Choice of Socket (Download)

    Angled Fixing Sockets Data Sheet (Download)

  • Technical Manual

    Threaded Socket Technical Manual (Download)

  • Certificates

    UKCA Declaration of Conformance (Download)

    EU CE Declaration of Conformance (Download)

    UK Test Certificate Example (Download)
